4140 Steel Guide: How to Balance Strength and Hardness？

4140 steel (domestic grade 42CrMo) is an excellent medium carbon alloy structural steel, known for its high strength, good toughness, wear resistance and hardenability. There is a close relationship between its strength and hardness, but the selection needs to be weighed according to the specific application requirements.

Core Principles:
Strength and hardness can usually be adjusted by heat treatment (mainly tempering temperature): the higher the hardness, the higher the strength (especially yield strength and tensile strength), but the toughness (impact toughness) usually decreases.

Here are the key considerations and guidelines for selecting the strength and hardness of 4140 steel:

1. Understand The Relationship Between Strength and Hardness:

• Strength: Mainly refers to the material’s ability to resist deformation (yield strength) and fracture (tensile strength). High-strength 4140 can withstand greater static or dynamic loads without plastic deformation or fracture.
• Hardness: Refers to the ability of a material to resist local plastic deformation (such as indentation, scratching). High-hardness 4140 is more wear-resistant and more resistant to surface damage.
• Correlation: For quenched and tempered steels such as 4140, hardness and strength have a strong positive correlation. Generally speaking, the higher the hardness, the higher the yield strength and tensile strength. This is because the performance of both is mainly determined by the same microstructural factors (martensite morphology, carbide precipitation, etc.).
• Trade-offs: Toughness (impact toughness) is a key trade-off. As hardness and strength increase, the toughness of the material generally decreases. This means that the material is more likely to fracture brittlely when subjected to impact loads or stress concentration.

2. Selection Basis – Application Scenarios and Performance Requirements:

High fatigue strength, impact load, and good toughness are required:

• Typical applications: shafts (drive shafts, crankshafts, camshafts), connecting rods, high-strength bolts, gears (tooth roots require toughness), pressure vessel components, oil drilling tools, key structural parts of engineering machinery.
• Recommended heat treatment: quenching and tempering.
• Target hardness range: Usually HRC 28 – 36 (or HB 280 – 350).
• Performance characteristics: Within this range, 4140 can obtain the best strength and toughness combination. It has high yield strength and tensile strength, while maintaining good plasticity and excellent impact toughness, and can effectively resist fatigue and impact failure.
• Why choose this range?  Avoid pursuing too high hardness and sacrificing toughness, resulting in sudden fracture of key components under impact or cyclic loads.

High surface hardness, excellent wear resistance, and wear resistance are required:

• Typical applications: Gears (tooth surfaces), sprockets, pins, wear-resistant liners, molds (certain types), fixtures, parts requiring high wear resistance.
• Recommended heat treatment:
  Overall quenching + low temperature tempering: suitable for parts with smaller size or hardenability that meet the requirements. Overall high hardness can be obtained.
  –Target hardness range: HRC 50 – 58+ (depending on the specific quenching process and cross-sectional size).
  –Performance characteristics: Extremely high surface and core hardness, excellent wear resistance, and high compressive strength. But toughness is significantly reduced, sensitive to notches, and not resistant to impact.
• Surface hardening:
  1.Induction hardening/flame hardening:Rapidly heat and harden only the surface area that needs wear resistance, and the core maintains the original (usually tempered) toughness.
  –Surface hardness:HRC 55 – 60+.
  –Core hardness:Usually tempered hardness (such as HRC 28-36), providing toughness support.
  2.Nitriding/nitrocarburizing:Infiltrate nitrogen atoms on the surface of the part to form an extremely hard compound layer and diffusion layer.
  –Surface hardness:HV 700 – 1100+ (about HRC 60-70), excellent wear resistance, seizure resistance, and fatigue strength.
  –Core hardness:Matrix hardness (usually requires tempering to around HRC 30 to obtain sufficient core strength to support the hard surface layer).
• Why choose high hardness? When wear is the main failure mode, high hardness is the primary consideration. Surface hardening is the best solution to the contradiction of “needing both hard surface (wear resistance) and tough core”.

Medium strength and good machinability (turning, milling, etc.) are required:

• Typical applications: Supplied in pre-hardened state (quenched and tempered by the steel mill), used to manufacture structural parts, fixtures, etc., can be directly processed to avoid subsequent heat treatment deformation.
• Target hardness range: HRC 28 – 32 (or HB 270 – 320) is more common. The material still has good strength at this hardness, and the machinability is much better than that of the high hardness state.
• Performance characteristics: Good comprehensive mechanical properties and machinability.

3. Key Failure Modes:

• If your parts are most likely to fail due to fatigue fracture or impact fracture, then prioritize sufficient toughness, choose quenched and tempered state (HRC 28-36), and the strength is also high enough.
• If your parts are most likely to fail due to wear (abrasive wear, adhesive wear, etc.) or surface crushing, then prioritize high surface hardness, choose throughput hardening state (HRC 50+) or surface hardening treatment.
• If fatigue and wear are both major threats (such as gears), surface hardening (induction hardening, nitriding) is the best choice.

4. Machinability and Cost:

• The higher the hardness, the more difficult the subsequent machining (turning, milling, drilling, etc.), the faster the tool wear, and the higher the cost. Pre-hardened (HRC 28-32) or tempered (HRC 28-36) are relatively easy to process.
• Surface hardening (induction hardening, nitriding) is usually more expensive and more complicated than full hardening, but it can obtain the best combination of surface and core properties.
• After full hardening to high hardness (HRC 50+), grinding is almost the only option.

Summary and Suggestions:

1. Preferred quenching and tempering: For most structural parts requiring high strength and good toughness (shafts, connecting rods, bolts, parts subject to dynamic loads), quenching and tempering to HRC 28 – 36 (HB 280 – 350) is the most common and optimal choice. This provides the best balance of strength and toughness.
2. High wear resistance requirements: When wear resistance is the primary requirement:

• Consider overall quenching + low temperature tempering (HRC 50-58+), but pay attention to the problems of low toughness and difficult processing.
• Surface hardening is preferred:
  –Induction hardening/flame hardening: Suitable for parts that require local high hardness (such as gear tooth surface, journal), surface HRC 55-60+, and the core remains tough.
  –Nitriding/Nitrocarburizing: Suitable for parts that require extremely high surface hardness, wear resistance, fatigue resistance, high dimensional accuracy and minimal deformation requirements (such as precision gears, hydraulic components). The surface hardness is extremely high (HV 700-1100+), and the core needs to be pre-tempered (~HRC 30).

3. Balanced machinability: If the part has a complex shape or requires a lot of machining, consider using a pre-hardened state (HRC 28-32) or designing it in a quenched and tempered state (HRC 28-36) for most of the machining, and then surface hardening (if necessary).
4. Consult professionals: For critical applications, be sure to consult a materials engineer or heat treatment expert. They can accurately recommend the most suitable 4140 steel grade (which may have different hardenability levels), heat treatment process and target hardness range based on your specific part design, load conditions (static load, dynamic load, impact), failure mode prediction, size and shape, cost budget and other factors, and perform necessary mechanical property test verification.

Simple Selection Based on Application Requirements

• To be strong and tough (resist impact and fatigue fracture): choose tempering, HRC 28-36.
• To have a hard surface (resist wear): choose surface quenching or nitriding, surface HRC 55+ or HV 700+.
• To be hard throughout (wear-resistant but not brittle): choose overall quenching, HRC 50+ (use with caution, pay attention to brittleness).
• To be easy to process: choose pre-hardening (HRC 28-32) or process in the tempered state.

The final choice of hardness and strength of 4140 steel is a comprehensive balance between performance requirements, manufacturability and cost.
